BW, BWJ(T) stainless steel Horizontal Multi-Stage Centrifugal Pumps are non-self-priming pumps absorbing the advanced technology from home and abroad. They are classified into two kinds: cylinder type and sectional type. They adopt a horizontal motor and alloy mechanical seal, which makes the replacement more convenient. The overflowing part of the pump is made of stainless steel 304, applicable for light-corrosion medium. Relying on the high efficiency, energy-saving performance, reliable quality, wide usable range, our products receive great popularity after being launched.

Application Limits

• Temperature range of medium: Normal type 0~+68? hot water type 0~+120?
• Maximum ambient temperature: +40?
• Maximum working pressure: 10 bar
• When the density or viscosity of the transmission medium exceeds that of water, it is necessary to select a driving motor of high-power.
• pH: 6.5 to 8.5

Applications Fields

• Air conditioner system
• Aquaculture
• Cooling System
• Industrial cleansing
• Environmental application
• Water processing (Water purification)
• Fertilization/measuring system
• Other special applications

Optional Available On Request

• Full-enclosed and ventilating two-pole standard motor
• Protection class: IP55
• Insulation class: F
• Standard voltage (50Hz): Single phase 220V Three-phase:380V or 220V
