Technical Parameters

• Water Pressure: 0.15—0.6MPa
• Water Temperature: 5℃-50℃
• Water Turbidity: ＜20FTU
• Inlet/Outlet: 1″F
• Drain: 1″F
• Base: 2.5″-8NPSM
• Riser Pipe: 1″D-GB
• Max Flow Rate: 6 m3/h
• Suitable Tank Size (in): 6″～14″

Product Characteristics：

• It adopts hermetic head faces with high degree pottery and corrosion resistance for opening and closing.
• No water passes the valve in rinse in single tank type.
• Reasonable design of the flow passage: Service→ Fast Rinse→ Backwash → Fast Rinse → Backwash →Service.
• It can be changed to be a side-mounted valve with side-mounted connector.
• It can operate under pressure, without leakage.

Range of Application：

• Residential filtration system
• Swimming pool filtration equipment
• Active carbon or sand filter in RO pretreatment filtration system
