🔍 UF Membrane AQU-250BR32985,00 UF Membrane AQU-250B quantity Add to cart Category: Uf Ultrafiltration Systems Brand: Pure Drop Description UF Membrane AQU-250B Ultrafiltration Components Parameters Model No. AQU-250PAN AQU-250PS AQU-250PP AQU-250PVDF Size Φ250X1713mm Φ250X1713mm Φ250X1713mm Φ250X1713mm Hollow fiber material PAN PS PP PVDF Hollow fiber ID/OD 1.0mm / 1.6mm 1.0mm / 1.6mm 0.4mm / 0.5mm 0.7mm / 1.3mm MWCO (Daltons) 50k～100k 10k～100k 50k～100k 100k～200k Membrane area 48m2 48m2 90m2 76m2 Filtration method Inside-out Outside-in Initial flux L/H, 0.1mpa, 25˚C pure water as feed >11000 >11000 >15300 >15000 Designed water flux 40-120L/m2/h 40-80L/m2/h End seal material Epoxy resins Housing material UPVC Connection/Pipe Coupling connection DN50 / PVC Pipe ID. 50mm Max. Feed pressure 0.3mpa 0.3mpa 0.3mpa 0.25mpa Max. trans-membrane pressure 0.2mpa 0.2mpa 0.2mpa 0.15mpa Normal trans-membrane pressure 0.02-0.15mpa 0.02-0.15mpa 0.02-0.15mpa 0.01-0.1mpa Feed turbidity <50ntu Permeate turbidity <0.1ntu Max. working temperature 5-45˚C PH range 3-9 2-12 1-14 2-13 Microorganism, pathogen 99.99% Removal Reviews (0) Reviews There are no reviews yet. Be the first to review “UF Membrane AQU-250B”Cancel ReplyYour email address will not be published. Required fields are marked *Your rating * Rate… Perfect Good Average Not that bad Very poor Name *Email *Your review * Save my name, email, and website in this browser for the next time I comment. Submit Related products UF Membrane AQU-250AUf Ultrafiltration Systems R28300,00 Add to cart Ultra Filtration System – Toppuror Brand With Purple MembraneUf Ultrafiltration Systems R1125,00 Add to cart UF Membrane AQU-160Uf Ultrafiltration Systems R9700,00 Add to cart
UF Membrane AQU-250B Ultrafiltration Components Parameters Model No. AQU-250PAN AQU-250PS AQU-250PP AQU-250PVDF Size Φ250X1713mm Φ250X1713mm Φ250X1713mm Φ250X1713mm Hollow fiber material PAN PS PP PVDF Hollow fiber ID/OD 1.0mm / 1.6mm 1.0mm / 1.6mm 0.4mm / 0.5mm 0.7mm / 1.3mm MWCO (Daltons) 50k～100k 10k～100k 50k～100k 100k～200k Membrane area 48m2 48m2 90m2 76m2 Filtration method Inside-out Outside-in Initial flux L/H, 0.1mpa, 25˚C pure water as feed >11000 >11000 >15300 >15000 Designed water flux 40-120L/m2/h 40-80L/m2/h End seal material Epoxy resins Housing material UPVC Connection/Pipe Coupling connection DN50 / PVC Pipe ID. 50mm Max. Feed pressure 0.3mpa 0.3mpa 0.3mpa 0.25mpa Max. trans-membrane pressure 0.2mpa 0.2mpa 0.2mpa 0.15mpa Normal trans-membrane pressure 0.02-0.15mpa 0.02-0.15mpa 0.02-0.15mpa 0.01-0.1mpa Feed turbidity <50ntu Permeate turbidity <0.1ntu Max. working temperature 5-45˚C PH range 3-9 2-12 1-14 2-13 Microorganism, pathogen 99.99% Removal
